CM-XLP-4021 Extremely Low Pressure RO membranes

Share to:
CM Extremely Low Pressure RO membranes are designed to operate at pressure of 100psi, less than 50% of the feed water pressure of standard high rejection membranes, and up to 30% of the feed water pressure of other low energy membranes. Extremely Low Pressure RO membranes are applicable for desalination treatment of those water resources that with low salinity and not requiring high rejection such as surface water, underground water, tap water, and municipal water.
Availability:
Quantity:

一,Product Description


CM Extremely Low Pressure RO membranes are designed to operate at pressure of 100psi, less than 50% of the feed water pressure of standard high rejection membranes, and up to 30% of the feed water pressure of other low energy membranes. Extremely Low Pressure RO membranes are applicable for desalination treatment of those water resources that with low salinity and not requiring high rejection such as surface water, underground water, tap water, and municipal water.


二,Characteristics


CM RO Membranes are available in customized sizes as well as standard sizes. All the elements are shipped in dry condition for ease of storage and handling.


Advantage


☞  Up to 99% of total dissolved solids removed.


☞  100% vacuum tested.


☞  Superior quality and consistent performance.


☞  Cost savings.


☞  Standard sizes to fit in commonly available housings.


☞  Using the most advanced membrane film technology and manufacturing processes


三,

Model No.

Average Permeate Flow Rate GPD(T)

Active Membrane Area ft²(m²)

Nominal Salt Rejection(%)

NaCl (ppm)

Appiled Pressure PsiMpa

Racovery Rate(%)

CM-XLE-2514

190(0.72)

8(0.7)

97

500

100(0.69)

5

CM-XLE-2521

365(1.38)

13(1.2)

97

8

CM-XLE-2540

850(3.22)

28(2.6)

97

15

CM-XLE-4014

540(2.0)

22(2.0)

98

5

CM-XLE-4021

950(3.60)

36(3.3)

98

8

CM-XLE-4040

2800(10.6)

78(7.2)

99

15

CM-XLE-8040

11000(41.6)

365(34)

99.5

15


Note: Performance specifications based on 500ppm NaCl feed water, 100psi(0.69MPa) applied pressure, 25°C(77°F), feed water PH 7-8 and recovery listed in the table above. Single element permeate flow may vary ±20%.
